- Make
| Anechoic Chamber | ETS-Lindgren |
| USB Vector Network Analyzer | Keysight |
| Signal Analyzer | Keysight |
| Signal Generator | Keysight |
| Double-Ridged Waveguide Horn | ETS-Lindgren |
| BiConiLog Antenna | ETS-Lindgren |
| EMC Software – Totally Integrated Lab Software | ETS-Lindgren |
| EMQuest – Antenna Measurement Software | ETS-Lindgren |
- Model
| Anechoic Chamber | 3 meter |
| USB Vector Network Analyzer | 9374A (upto 20 GHz) |
| Signal Analyzer | N9010B (10 Hz to 26.5 GHz) |
| Signal Generator | N5173B (9 KHz to 20 GHz) |
| Double-Ridged Waveguide Horn | 3115 (750 MHz – 18 GHz) |
| BiConiLog Antenna | 3142E (30 MHz to 6 GHz) |
- Capabilities
For booking a specific experiment please click the ‘View details’.
- Antenna Measurement from 750 MHz to 18 GHz
- Return Loss
- Gain Measurement
- Radiation Pattern Measurement (Co and Cross)
- Insertion loss / shielding effectiveness measurement of planar samples from 750 MHz to 18 GHz in free space
- Microwave device testing upto 26.5 GHz
- S-Parameter measurement of Material Sample in X-band
- Pre-compliance Radiated Emission Measurement as per CISPR22 standard
- Applications
Field measurements and material characterization at RF and Microwave frequencies.
- Location
EMC/Wireless Test Chamber,
G-07, CDMM Ground Floor.
- Contact
Dr. V. Rajeshkumar,
Professor,
Department of Communication Engineering,
School of Electronics Engineering (SENSE),
Vellore Institute of Technology, Vellore, Tamil Nadu. Pin: 632014.
Email: emc.wirelesstest@vit.ac.in
Phone: 9003535984
