Make: Chroma ATE Inc.
Model: 62050H-600S DC power supply
- Capabilities
Key Specifications
- Rated Output Power: 5 kW
- Output Voltage Range: 0 – 600 V DC
- Output Current Range: 0 – 8.5 A
- Solar Array Simulation (SAS) function for PV inverter and MPPT testing
- High-accuracy I-V curve simulation with programmable irradiance and temperature effects
- Fast transient response for dynamic load testing
- Low output ripple and noise using high-frequency PWM technology
- High power density – compact 3U rack-mount design
- Master/Slave parallel or series operation for higher power or voltage expansion
- Built-in protection functions: OVP, OCP, OTP, and power limit
- 16-bit precision control for accurate voltage and current programming and readback
- Programmable slew rate control for voltage/current transitions
- Sequence programming for custom voltage/current profiles
- Remote interfaces: USB, RS-232, RS-485 standard; optional GPIB and Ethernet
- Digital control & monitoring via Chroma SoftPanel software or external SCPI commands
- Supports remote sensing to compensate for voltage drops across cables
- Power factor correction (PFC) for efficient AC input use
- Comprehensive protection & self-diagnosis for reliable long-term operation
- Applications
- PV inverter and MPPT algorithm testing
- DC/DC converter and inverter input testing
- Battery charge/discharge simulation
- Power electronics R&D and automated test systems
- Charges
| S. No. | Experiment Details | Students (UG/PG)/Research Scholars from VIT | UG /PG Students from Academic Institutions (in INR) | Research Scholar from Academic Institution (in INR) | Project Staff from Academic Institution (in INR) | Faculty Members from Academic Institutions (in INR) | Research Scientist from R&D Organizations (in INR) | Industry Personnel from Industry (in INR) |
|---|---|---|---|---|---|---|---|---|
| 1 | Depending on the project setup | 1000/day | 1000/day | 1500/day | 1500/day | 2000/day | 2000/day | 2000/day |
* Charges for per sample in INR(+ applicable GST)
- Location
Room No.: TT044
Power Electronics and Drives Lab, SELECT
Vellore Institute of Technology (VIT), Vellore.
- Contact
Dr. Mrutunjaya Panda,
Assistant Professor
Power Electronics and Drives Lab, SELECT
Vellore Institute of Technology (VIT), Vellore – 632 014, Tamil Nadu, India
Email: mrutunjaya.panda@vit.ac.in
Faculty in charge email id: mrutunjaya.panda@vit.ac.in
Instrument emailID: Yet to receive
