Make: NF Corporation Japan
Model: ZM2378
Frequency range : 1 mHz ‑ 5.5 MHz.
Basic accuracy : 0.08%.
Measurement signal : 10 mVrms ‑ 5 Vrms, 1 µArms ‑ 200 mArms.
DC bias : Internal 0‑2.5 V or 0‑5.0 V
Measurement time / speed : High-speed modes,typical ≈2 ms
Measured parameters : |Z|, |Y|, L, C, R, G (plus Q, D, θ, X, B, Rs, Rp
Basic accuracy : 0.08%.
Measurement signal : 10 mVrms ‑ 5 Vrms, 1 µArms ‑ 200 mArms.
DC bias : Internal 0‑2.5 V or 0‑5.0 V
Measurement time / speed : High-speed modes,typical ≈2 ms
Measured parameters : |Z|, |Y|, L, C, R, G (plus Q, D, θ, X, B, Rs, Rp
Capacitance, Inductance, and Resistance (LCR) Measurements
- Precise measurement of passive components under controlled temperature.
- Helps in characterizing behaviour across a wide temperature range.
- Evaluates how dielectric, magnetic, and conductive properties vary with temperature.
- Essential for materials used in harsh or varying environmental conditions.
Room No.: 505- Technology Tower,
Ceramic composites Laboratory,
Centre for Functional Materials,
Vellore Institute of Technology (VIT), Vellore.
Ceramic composites Laboratory,
Centre for Functional Materials,
Vellore Institute of Technology (VIT), Vellore.
Dr.Madhuri W
505- Technology Tower
Ceramic composites Laboratory,
Centre for Functional Materials (CFM),
Vellore Institute of Technology - Vellore Campus,
Thiruvalam Road, Vellore – 632 014, Tamil Nadu, India.
Office Phone: +91 – 416 – 220 2353
Instrument email ID: cfm.lcr@vit.ac.in
505- Technology Tower
Ceramic composites Laboratory,
Centre for Functional Materials (CFM),
Vellore Institute of Technology - Vellore Campus,
Thiruvalam Road, Vellore – 632 014, Tamil Nadu, India.
Office Phone: +91 – 416 – 220 2353
Instrument email ID: cfm.lcr@vit.ac.in
| S. No. | Experiment Details | UG /PG Students from Academic Institutions (in INR) | Research Scholar from Academic Institution (in INR) | Project Staff from Academic Institution (in INR) | Faculty Members from Academic Institutions (in INR) | Research Scientist from R&D Organizations (in INR) | Industry Personnel from Industry (in INR) |
|---|---|---|---|---|---|---|---|
| 1 | Electrospining machine | 1000 | 2000 | 2000 | 2000 | 3000 | 3000 |
* Charges for per sample in INR (+ applicable GST)
