Make: Keysight Technology
Model: MSOX3014G
Key Specifications
- Bandwidth: 100 MHz (typical model)
- Analog channels: 4
- Digital channels: 16 (for MSO version)
- Maximum sample rate: up to 4 GSa/s (depending on configuration)
- Memory depth: up to 4 Mpts (optional)
- Waveform update rate: up to 1 000 000 waveforms
- Display: 8.5-inch capacitive touch screen (WVGA)
- Built-in instruments: Function/Arbitrary Waveform Generator (20 MHz), DVM, 8-digit counter/totaliser in many models)
- Upgradability: bandwidth, memory, options (serial protocol decode, digital channels) can be added later.
- Analyze both analog and digital signals simultaneously (4 analog + 16 digital).
- Ideal for debugging microcontrollers, FPGAs, and DSP-based systems.
- Measure and analyze switching waveforms, ripple, and transient response.
- Evaluate SMPS, inverters, and motor control circuits.
- Supports decoding and triggering for protocols such as: I²C, SPI, UART/RS232, CAN, LIN, I²S, and USB 2.0.
- Great for automotive and industrial communication testing.
- Correlate digital logic timing with analog signal behavior in real time.
- Perfect for verifying timing relationships between control and feedback loops.
- Widely used in engineering labs for teaching measurement and control concepts.
- Provides an intuitive touchscreen interface and auto-setup functions for easy learning.
- Perform basic frequency domain (FFT) and modulation analysis for low-frequency RF applications.
Room No.: TT044
Power Electronics and Drives Lab, SELECT
Vellore Institute of Technology (VIT), Vellore.
Power Electronics and Drives Lab, SELECT
Vellore Institute of Technology (VIT), Vellore.
Dr. Mrutunjaya Panda,
Assistant Professor
Power Electronics and Drives Lab, SELECT
Vellore Institute of Technology (VIT), Vellore - 632 014, Tamil Nadu, India
Email: mrutunjaya.panda@vit.ac.in
Faculty in charge email id: mrutunjaya.panda@vit.ac.in
Instrument emailID: Yet to receive
Assistant Professor
Power Electronics and Drives Lab, SELECT
Vellore Institute of Technology (VIT), Vellore - 632 014, Tamil Nadu, India
Email: mrutunjaya.panda@vit.ac.in
Faculty in charge email id: mrutunjaya.panda@vit.ac.in
Instrument emailID: Yet to receive
| S. No. | Experiment Details | Students (UG/PG)/Research Scholars from VIT | UG /PG Students from Academic Institutions (in INR) | Research Scholar from Academic Institution (in INR) | Project Staff from Academic Institution (in INR) | Faculty Members from Academic Institutions (in INR) | Research Scientist from R&D Organizations (in INR) | Industry Personnel from Industry (in INR) |
|---|---|---|---|---|---|---|---|---|
| 1 | Depending on the project setup | 1000/day | 1000/day | 1500/day | 1500/day | 2000/day | 2000/day | 2000/day |
