Make: Chroma ATE Inc.
Model: 62050H-600S DC power supply
Key Specifications
- Rated Output Power: 5 kW
- Output Voltage Range: 0 - 600 V DC
- Output Current Range: 0 - 8.5 A
- Solar Array Simulation (SAS) function for PV inverter and MPPT testing
- High-accuracy I-V curve simulation with programmable irradiance and temperature effects
- Fast transient response for dynamic load testing
- Low output ripple and noise using high-frequency PWM technology
- High power density - compact 3U rack-mount design
- Master/Slave parallel or series operation for higher power or voltage expansion
- Built-in protection functions: OVP, OCP, OTP, and power limit
- 16-bit precision control for accurate voltage and current programming and readback
- Programmable slew rate control for voltage/current transitions
- Sequence programming for custom voltage/current profiles
- Remote interfaces: USB, RS-232, RS-485 standard; optional GPIB and Ethernet
- Digital control & monitoring via Chroma SoftPanel software or external SCPI commands
- Supports remote sensing to compensate for voltage drops across cables
- Power factor correction (PFC) for efficient AC input use
- Comprehensive protection & self-diagnosis for reliable long-term operation
- PV inverter and MPPT algorithm testing
- DC/DC converter and inverter input testing
- Battery charge/discharge simulation
- Power electronics R&D and automated test systems
Room No.: TT044
Power Electronics and Drives Lab, SELECT
Vellore Institute of Technology (VIT), Vellore.
Power Electronics and Drives Lab, SELECT
Vellore Institute of Technology (VIT), Vellore.
Dr. Mrutunjaya Panda,
Assistant Professor
Power Electronics and Drives Lab, SELECT
Vellore Institute of Technology (VIT), Vellore - 632 014, Tamil Nadu, India
Email: mrutunjaya.panda@vit.ac.in
Faculty in charge email id: mrutunjaya.panda@vit.ac.in
Instrument emailID: Yet to receive
Assistant Professor
Power Electronics and Drives Lab, SELECT
Vellore Institute of Technology (VIT), Vellore - 632 014, Tamil Nadu, India
Email: mrutunjaya.panda@vit.ac.in
Faculty in charge email id: mrutunjaya.panda@vit.ac.in
Instrument emailID: Yet to receive
| S. No. | Experiment Details | Students (UG/PG)/Research Scholars from VIT | UG /PG Students from Academic Institutions (in INR) | Research Scholar from Academic Institution (in INR) | Project Staff from Academic Institution (in INR) | Faculty Members from Academic Institutions (in INR) | Research Scientist from R&D Organizations (in INR) | Industry Personnel from Industry (in INR) |
|---|---|---|---|---|---|---|---|---|
| 1 | Depending on the project setup | 1000/day | 1000/day | 1500/day | 1500/day | 2000/day | 2000/day | 2000/day |
